Mouse Norrin (Ndp) ELISA Kit (MOEB1356)

SKU:
MOEB1356
Product Type:
ELISA Kit
Size:
96 Assays
Uniprot:
P48744
Range:
0.312-20 ng/mL
ELISA Type:
Sandwich
Reactivity:
Mouse
€649

Description

system_update_altDatasheetsystem_update_altMSDS

Mouse Norrin (Ndp) ELISA Kit

The Mouse Norrin (NDP) ELISA Kit is specifically designed for the precise measurement of Norrin levels in mouse serum, plasma, and cell culture supernatants. This kit offers unmatched sensitivity and specificity, ensuring accurate and consistent results for various research applications.Norrin, also known as NDP (Norrie disease protein), is a key signaling protein that plays a critical role in the development of the vascular system and the formation of blood vessels. Dysregulation of Norrin has been linked to various diseases, including retinal disorders and vascular abnormalities, making it a crucial biomarker for studying these conditions and developing potential therapeutic interventions.

With its high-performance capabilities, the Mouse Norrin (NDP) ELISA Kit is an indispensable tool for researchers looking to investigate the role of Norrin in health and disease, providing valuable insights into potential treatment strategies for associated disorders.

Product Name:Mouse Norrin (Ndp) ELISA Kit
SKU:MOEB1356
Size:96T
Target:Mouse Norrin (Ndp)
Synonyms:Norrie disease protein homolog, Ndph
Assay Type:Sandwich
Detection Method:ELISA
Reactivity:Mouse
Detection Range:0.312-20ng/mL
Sensitivity:0.156ng/mL
Intra CV:5.2%
Inter CV:8.1%
Linearity:
Sample1:21:41:81:16
Serum(N=5)100-110%106-118%85-94%80-90%
EDTA Plasma(N=5)87-96%98-109%107-117%108-118%
Heparin Plasma(N=5)98-108%106-117%83-92%80-93%
Recovery:
Sample TypeAverage(%)Recovery Range(%)
Serum10094-106
Plasma10296-108
Function:Activates the canonical Wnt signaling pathway through FZD4 and LRP5 coreceptor. Plays a central role in retinal vascularization by acting as a ligand for FZD4 that signals via stabilizing beta-catenin (CTNNB1) and activating LEF/TCF-mediated transcriptional programs. Acts in concert with TSPAN12 to activate FZD4 independently of the Wnt-dependent activation of FZD4, suggesting the existence of a Wnt-independent signaling that also promote accumulation the beta-catenin (CTNNB1). May be involved in a pathway that regulates neural cell differentiation and proliferation. Possible role in neuroectodermal cell-cell interaction.
Uniprot:P48744
Sample Type:Serum, plasma, tissue homogenates, cell culture supernates and other biological fluids
Specificity:Natural and recombinant mouse Norrin
Sub Unit:Homodimer; disulfide-linked (By similarity). Component of a complex, at least composed of TSPAN12, FZD4, LRP5/6 and norrin (NDP). Binds FZD4 with high affinity. Interacts with LRP6 (via Beta-propellers 1 and 2).
Research Area:Cancer
Subcellular Location:Secreted
Storage:Please see kit components below for exact storage details
Note:For research use only
UniProt Protein Function:NDP: Activates the canonical Wnt signaling pathway through FZD4 and LRP5 coreceptor. Plays a central role in retinal vascularization by acting as a ligand for FZD4 that signals via stabilizing beta-catenin (CTNNB1) and activating LEF/TCF-mediated transcriptional programs. Acts in concert with TSPAN12 to activate FZD4 independently of the Wnt-dependent activation of FZD4, suggesting the existence of a Wnt-independent signaling that also promote accumulation the beta-catenin (CTNNB1). May be involved in a pathway that regulates neural cell differentiation and proliferation. Possible role in neuroectodermal cell-cell interaction. Defects in NDP are the cause of Norrie disease (ND); also known as atrophia bulborum hereditaria or Episkopi blindness. ND is a recessive disorder characterized by very early childhood blindness due to degenerative and proliferative changes of the neuroretina. Approximately 50% of patients show some form of progressive mental disorder, often with psychotic features, and about one-third of patients develop sensorineural deafness in the second decade. In addition, some patients have more complex phenotypes, including growth failure and seizure. Defects in NDP are the cause of vitreoretinopathy exudative type 2 (EVR2). EVR2 is a disorder of the retinal vasculature characterized by an abrupt cessation of growth of peripheral capillaries, leading to an avascular peripheral retina. This may lead to compensatory retinal neovascularization, which is thought to be induced by hypoxia from the initial avascular insult. New vessels are prone to leakage and rupture causing exudates and bleeding, followed by scarring, retinal detachment and blindness. Clinical features can be highly variable, even within the same family. Patients with mild forms of the disease are asymptomatic, and their only disease related abnormality is an arc of avascular retina in the extreme temporal periphery.Protein type: Secreted, signal peptide; SecretedCellular Component: cell surface; extracellular matrix; extracellular region; extracellular spaceMolecular Function: cytokine activity; frizzled binding; protein homodimerization activityBiological Process: placenta development; positive regulation of transcription factor activity; positive regulation of transcription, DNA-dependent; Wnt receptor signaling pathway; Wnt receptor signaling pathway through beta-catenin
UniProt Protein Details:
NCBI Summary:This gene encodes a secreted protein that acts a ligand for multiple different receptors and participates in both Wnt and Wnt-independant signalling. Its activity is important in vascular development of the eye and inner ear. Mutation of the related gene in humans causes Norrie syndrome. [provided by RefSeq, May 2015]
UniProt Code:P48744
NCBI GenInfo Identifier:6754808
NCBI Gene ID:17986
NCBI Accession:NP_035013.1
UniProt Secondary Accession:P48744,Q5CZY6
UniProt Related Accession:P48744
Molecular Weight:14,700 Da
NCBI Full Name:norrin
NCBI Synonym Full Names:Norrie disease (pseudoglioma) (human)
NCBI Official Symbol:Ndp
NCBI Official Synonym Symbols:ND; Ndph
NCBI Protein Information:norrin
UniProt Protein Name:Norrin
UniProt Synonym Protein Names:Norrie disease protein homolog
Protein Family:Norrin
UniProt Gene Name:Ndp
UniProt Entry Name:NDP_MOUSE
Component Quantity (96 Assays) Storage
ELISA Microplate (Dismountable) 8×12 strips -20°C
Lyophilized Standard 2 -20°C
Sample Diluent 20ml -20°C
Assay Diluent A 10mL -20°C
Assay Diluent B 10mL -20°C
Detection Reagent A 120µL -20°C
Detection Reagent B 120µL -20°C
Wash Buffer 30mL 4°C
Substrate 10mL 4°C
Stop Solution 10mL 4°C
Plate Sealer 5 -

Other materials and equipment required:

  • Microplate reader with 450 nm wavelength filter
  • Multichannel Pipette, Pipette, microcentrifuge tubes and disposable pipette tips
  • Incubator
  • Deionized or distilled water
  • Absorbent paper
  • Buffer resevoir

*Note: The below protocol is a sample protocol. Protocols are specific to each batch/lot. For the correct instructions please follow the protocol included in your kit.

Allow all reagents to reach room temperature (Please do not dissolve the reagents at 37°C directly). All the reagents should be mixed thoroughly by gently swirling before pipetting. Avoid foaming. Keep appropriate numbers of strips for 1 experiment and remove extra strips from microtiter plate. Removed strips should be resealed and stored at -20°C until the kits expiry date. Prepare all reagents, working standards and samples as directed in the previous sections. Please predict the concentration before assaying. If values for these are not within the range of the standard curve, users must determine the optimal sample dilutions for their experiments. We recommend running all samples in duplicate.

Step
1. Add Sample: Add 100µL of Standard, Blank, or Sample per well. The blank well is added with Sample diluent. Solutions are added to the bottom of micro ELISA plate well, avoid inside wall touching and foaming as possible. Mix it gently. Cover the plate with sealer we provided. Incubate for 120 minutes at 37°C.
2. Remove the liquid from each well, don't wash. Add 100µL of Detection Reagent A working solution to each well. Cover with the Plate sealer. Gently tap the plate to ensure thorough mixing. Incubate for 1 hour at 37°C. Note: if Detection Reagent A appears cloudy warm to room temperature until solution is uniform.
3. Aspirate each well and wash, repeating the process three times. Wash by filling each well with Wash Buffer (approximately 400µL) (a squirt bottle, multi-channel pipette,manifold dispenser or automated washer are needed). Complete removal of liquid at each step is essential. After the last wash, completely remove remaining Wash Buffer by aspirating or decanting. Invert the plate and pat it against thick clean absorbent paper.
4. Add 100µL of Detection Reagent B working solution to each well. Cover with the Plate sealer. Incubate for 60 minutes at 37°C.
5. Repeat the wash process for five times as conducted in step 3.
6. Add 90µL of Substrate Solution to each well. Cover with a new Plate sealer and incubate for 10-20 minutes at 37°C. Protect the plate from light. The reaction time can be shortened or extended according to the actual color change, but this should not exceed more than 30 minutes. When apparent gradient appears in standard wells, user should terminatethe reaction.
7. Add 50µL of Stop Solution to each well. If color change does not appear uniform, gently tap the plate to ensure thorough mixing.
8. Determine the optical density (OD value) of each well at once, using a micro-plate reader set to 450 nm. User should open the micro-plate reader in advance, preheat the instrument, and set the testing parameters.
9. After experiment, store all reagents according to the specified storage temperature respectively until their expiry.

When carrying out an ELISA assay it is important to prepare your samples in order to achieve the best possible results. Below we have a list of procedures for the preparation of samples for different sample types.

Sample Type Protocol
Serum If using serum separator tubes, allow samples to clot for 30 minutes at room temperature. Centrifuge for 10 minutes at 1,000x g. Collect the serum fraction and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles. If serum separator tubes are not being used, allow samples to clot overnight at 2-8°C. Centrifuge for 10 minutes at 1,000x g. Remove serum and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles.
Plasma Collect plasma using EDTA or heparin as an anticoagulant. Centrifuge samples at 4°C for 15 mins at 1000 × g within 30 mins of collection. Collect the plasma fraction and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles. Note: Over haemolysed samples are not suitable for use with this kit.
Urine & Cerebrospinal Fluid Collect the urine (mid-stream) in a sterile container, centrifuge for 20 mins at 2000-3000 rpm. Remove supernatant and assay immediately. If any precipitation is detected, repeat the centrifugation step. A similar protocol can be used for cerebrospinal fluid.
Cell culture supernatant Collect the cell culture media by pipette, followed by centrifugation at 4°C for 20 mins at 1500 rpm. Collect the clear supernatant and assay immediately.
Cell lysates Solubilize cells in lysis buffer and allow to sit on ice for 30 minutes. Centrifuge tubes at 14,000 x g for 5 minutes to remove insoluble material. Aliquot the supernatant into a new tube and discard the remaining whole cell extract. Quantify total protein concentration using a total protein assay. Assay immediately or aliquot and store at ≤ -20 °C.
Tissue homogenates The preparation of tissue homogenates will vary depending upon tissue type. Rinse tissue with 1X PBS to remove excess blood & homogenize in 20ml of 1X PBS (including protease inhibitors) and store overnight at ≤ -20°C. Two freeze-thaw cycles are required to break the cell membranes. To further disrupt the cell membranes you can sonicate the samples. Centrifuge homogenates for 5 mins at 5000xg. Remove the supernatant and assay immediately or aliquot and store at -20°C or -80°C.
Tissue lysates Rinse tissue with PBS, cut into 1-2 mm pieces, and homogenize with a tissue homogenizer in PBS. Add an equal volume of RIPA buffer containing protease inhibitors and lyse tissues at room temperature for 30 minutes with gentle agitation. Centrifuge to remove debris. Quantify total protein concentration using a total protein assay. Assay immediately or aliquot and store at ≤ -20 °C.
Breast Milk Collect milk samples and centrifuge at 10,000 x g for 60 min at 4°C. Aliquot the supernatant and assay. For long term use, store samples at -80°C. Minimize freeze/thaw cycles.
