Mouse Beta-type platelet-derived growth factor receptor (Pdgfrb) ELISA Kit (MOEB1890)

SKU:
MOEB1890
Product Type:
ELISA Kit
Size:
96 Assays
Uniprot:
P05622
Range:
0.156-10 ng/ml
ELISA Type:
Sandwich
Reactivity:
Mouse
€649
Frequently bought together:

Description

system_update_altDatasheetsystem_update_altMSDS

Mouse Beta-type platelet-derived growth factor receptor (Pdgfrb) ELISA Kit

The Mouse Beta Type Platelet-Derived Growth Factor Receptor (PDGFRB) ELISA Kit is a reliable and accurate tool for the detection of PDGFRB levels in mouse serum, plasma, and cell culture supernatants. This kit boasts high sensitivity and specificity, ensuring precise and reproducible results for a variety of research applications.PDGFRB is a key receptor involved in cellular functions such as cell growth, differentiation, and migration. It plays a crucial role in various physiological processes and pathological conditions, including cancer, fibrosis, and vascular diseases.

The ability to quantify PDGFRB levels with this ELISA kit makes it an invaluable resource for studying these pathways and potential therapeutic interventions.Overall, the Mouse Beta Type Platelet-Derived Growth Factor Receptor (PDGFRB) ELISA Kit offers accurate and reliable measurements of PDGFRB levels, making it an essential tool for researchers in the fields of cancer biology, vascular biology, and drug development.

Product Name:Mouse Beta-type platelet-derived growth factor receptor (Pdgfrb) ELISA Kit
SKU:MOEB1890
Size:96T
Target:Mouse Beta-type platelet-derived growth factor receptor (Pdgfrb)
Synonyms:Beta platelet-derived growth factor receptor, Beta-type platelet-derived growth factor receptor, CD140 antigen-like family member B, Platelet-derived growth factor receptor 1, PDGFR-1, CD140b, PDGF-R-beta, Pdgfr, Pdgfr1
Assay Type:Sandwich
Detection Method:ELISA
Reactivity:Mouse
Detection Range:0.156-10ng/ml
Sensitivity:0.087ng/mL
Intra CV:6.6%
Inter CV:8.5%
Linearity:
Sample1:21:41:81:16
Serum(N=5)102-112%102-112%100-108%95-106%
EDTA Plasma(N=5)84-96%119-129%110-110%91-101%
Heparin Plasma(N=5)98-108%104-113%92-105%109-119%
Recovery:
Sample TypeAverage(%)Recovery Range(%)
Serum8680-92
Plasma8882-94
Function:Tyrosine-protein kinase that acts as cell-surface receptor for homodimeric PDGFB and PDGFD and for heterodimers formed by PDGFA and PDGFB, and plays an essential role in the regulation of embryonic development, cell proliferation, survival, differentiation, chemotaxis and migration. Plays an essential role in blood vessel development by promoting proliferation, migration and recruitment of pericytes and smooth muscle cells to endothelial cells. Plays a role in the migration of vascular smooth muscle cells and the formation of neointima at vascular injury sites. Required for normal development of the cardiovascular system. Required for normal recruitment of pericytes (mesangial cells) in the kidney glomerulus, and for normal formation of a branched network of capillaries in kidney glomeruli. Promotes rearrangement of the actin cytoskeleton and the formation of membrane ruffles. Binding of its cognate ligands - homodimeric PDGFB, heterodimers formed by PDGFA and PDGFB or homodimeric PDGFD -leads to the activation of several signaling cascades; the response depends on the nature of the bound ligand and is modulated by the formation of heterodimers between PDGFRA and PDGFRB. Phosphorylates PLCG1, PIK3R1, PTPN11, RASA1/GAP, CBL, SHC1 and NCK1. Activation of PLCG1 leads to the production of the cellular signaling molecules diacylglycerol and inositol 1,4,5-trisphosphate, mobilization of cytosolic Ca(2+) and the activation of protein kinase C. Phosphorylation of PIK3R1, the regulatory subunit of phosphatidylinositol 3-kinase, leads to the activation of the AKT1 signaling pathway. Phosphorylation of SHC1, or of the C-terminus of PTPN11, creates a binding site for GRB2, resulting in the activation of HRAS, RAF1 and down-stream MAP kinases, including MAPK1/ERK2 and/or MAPK3/ERK1. Promotes phosphorylation and activation of SRC family kinases. Promotes phosphorylation of PDCD6IP/ALIX and STAM (By similarity). Receptor signaling is down-regulated by protein phosphatases that dephosphorylate the receptor and its down-stream effectors, and by rapid internalization of the activated receptor.
Uniprot:P05622
Sample Type:Serum, plasma, tissue homogenates, cell culture supernates and other biological fluids
Specificity:Natural and recombinant mouse Platelet-derived growth factor receptor beta
Sub Unit:Interacts with homodimeric PDGFB and PDGFD, and with heterodimers formed by PDGFA and PDGFB. May also interact with homodimeric PDGFC. Monomer in the absence of bound ligand. Interaction with homodimeric PDGFB, heterodimers formed by PDGFA and PDGFB or homodimeric PDGFD, leads to receptor dimerization, where both PDGFRA homodimers and heterodimers with PDGFRB are observed. Interacts with SH2B2/APS. Interacts directly (tyrosine phosphorylated) with SHB. Interacts (tyrosine phosphorylated) with PIK3R1 and RASA1. Interacts (tyrosine phosphorylated) with CBL. Interacts (tyrosine phosphorylated) with SRC and SRC family kinases. Interacts (tyrosine phosphorylated) with PIK3C2B, maybe indirectly. Interacts (tyrosine phosphorylated) with SHC1, GRB7, GRB10 and NCK1. Interaction with GRB2 is mediated by SHC1. Interacts (via C-terminus) with SLC9A3R1.
Research Area:Signal Transduction
Subcellular Location:Cell membrane Single-pass type I membrane protein Cytoplasmic vesicle Lysosome lumen After ligand binding, the autophosphorylated receptor is ubiquitinated and internalized, leading to its degradation.
Storage:Please see kit components below for exact storage details
Note:For research use only
UniProt Protein Function:PDGFRB: a receptor tyrosine kinase of the PDGFR family that binds members of the platelet-derived growth factor family. The identity of the growth factor bound determines whether the functional receptor is a homodimer or a heterodimer, composed of both PDGFR-alpha and -beta. Ligand binding induces receptor dimerization and autophosphorylation, thereby recruiting SH2-containing proteins including Grb2, Src, GAP, PTPN11, PI3 kinase, PLC-gamma and Nck. Regulates cell growth, actin reorganization, migration and differentiation. A variety of myeloproliferative disorders and cancers result from translocations that activate PDGFRbeta by fusion with proteins such as TEL/ETV6, H2, CEV14/TRP11, rabaptin 5, and huntington interacting protein 1. Gleevec treatment of TEL fusions has been successful. Overexpressed in metastatic medulloblastoma. Inhibitors: Gleevec, Sutent.Protein type: Membrane protein, integral; EC 2.7.10.1; Protein kinase, tyrosine (receptor); Oncoprotein; Protein kinase, TK; Kinase, protein; TK group; PDGFR familyCellular Component: cell surface; focal adhesion; membrane; lysosome; cytoplasm; apical plasma membrane; integral to membrane; plasma membrane; cytoplasmic vesicle; nucleus; intrinsic to plasma membraneMolecular Function: platelet-derived growth factor binding; nucleotide binding; platelet-derived growth factor receptor binding; platelet-derived growth factor receptor activity; transmembrane receptor protein tyrosine kinase activity; protein kinase binding; protein kinase activity; transferase activity; protein binding; signal transducer activity; protein-tyrosine kinase activity; platelet-derived growth factor beta-receptor activity; transferase activity, transferring phosphorus-containing groups; phosphoinositide 3-kinase binding; kinase activity; ATP binding; receptor bindingBiological Process: positive regulation of phosphoprotein phosphatase activity; peptidyl-tyrosine phosphorylation; positive regulation of smooth muscle cell proliferation; multicellular organismal development; protein amino acid autophosphorylation; positive regulation of collagen biosynthetic process; platelet-derived growth factor receptor signaling pathway; cardiac myofibril assembly; chemotaxis; signal transduction; positive regulation of smooth muscle cell migration; protein amino acid phosphorylation; smooth muscle development; positive regulation of MAP kinase activity; nitrogen compound metabolic process; positive regulation of cell proliferation; tissue homeostasis; hemopoiesis; phosphatidylinositol metabolic process; kidney development; regulation of peptidyl-tyrosine phosphorylation; cell migration; phosphoinositide-mediated signaling; positive regulation of mitosis; adrenal gland development; in utero embryonic development; positive regulation of chemotaxis; positive regulation of phosphoinositide 3-kinase activity; positive regulation of phosphoinositide 3-kinase cascade; glycosaminoglycan biosynthetic process; skeletal morphogenesis; regulation of actin cytoskeleton organization and biogenesis; phosphorylation; transmembrane receptor protein tyrosine kinase signaling pathway; negative regulation of apoptosis; positive regulation of cell migration
UniProt Protein Details:
NCBI Summary:
UniProt Code:P05622
NCBI GenInfo Identifier:226342982
NCBI Gene ID:18596
NCBI Accession:NP_001139740.1
UniProt Secondary Accession:P05622
UniProt Related Accession:P05622
Molecular Weight:122,806 Da
NCBI Full Name:platelet-derived growth factor receptor beta isoform 1
NCBI Synonym Full Names:platelet derived growth factor receptor, beta polypeptide
NCBI Official Symbol:Pdgfrb
NCBI Official Synonym Symbols:Pdgfr; CD140b; PDGFR-1; AI528809
NCBI Protein Information:platelet-derived growth factor receptor beta; PDGFR-beta; PDGF-R-beta; PDGF beta chain; CD140 antigen-like family member B; platelet-derived growth factor receptor 1; beta platelet-derived growth factor receptor; beta-type platelet-derived growth factor receptor; platelet-derived growth factor receptor beta variant 1
UniProt Protein Name:Platelet-derived growth factor receptor beta
UniProt Synonym Protein Names:Beta platelet-derived growth factor receptor; Beta-type platelet-derived growth factor receptor; CD140 antigen-like family member B; Platelet-derived growth factor receptor 1; PDGFR-1; CD_antigen: CD140b
Protein Family:Platelet-derived growth factor receptor
UniProt Gene Name:Pdgfrb
UniProt Entry Name:PGFRB_MOUSE
Component Quantity (96 Assays) Storage
ELISA Microplate (Dismountable) 8×12 strips -20°C
Lyophilized Standard 2 -20°C
Sample Diluent 20ml -20°C
Assay Diluent A 10mL -20°C
Assay Diluent B 10mL -20°C
Detection Reagent A 120µL -20°C
Detection Reagent B 120µL -20°C
Wash Buffer 30mL 4°C
Substrate 10mL 4°C
Stop Solution 10mL 4°C
Plate Sealer 5 -

Other materials and equipment required:

  • Microplate reader with 450 nm wavelength filter
  • Multichannel Pipette, Pipette, microcentrifuge tubes and disposable pipette tips
  • Incubator
  • Deionized or distilled water
  • Absorbent paper
  • Buffer resevoir

*Note: The below protocol is a sample protocol. Protocols are specific to each batch/lot. For the correct instructions please follow the protocol included in your kit.

Allow all reagents to reach room temperature (Please do not dissolve the reagents at 37°C directly). All the reagents should be mixed thoroughly by gently swirling before pipetting. Avoid foaming. Keep appropriate numbers of strips for 1 experiment and remove extra strips from microtiter plate. Removed strips should be resealed and stored at -20°C until the kits expiry date. Prepare all reagents, working standards and samples as directed in the previous sections. Please predict the concentration before assaying. If values for these are not within the range of the standard curve, users must determine the optimal sample dilutions for their experiments. We recommend running all samples in duplicate.

Step
1. Add Sample: Add 100µL of Standard, Blank, or Sample per well. The blank well is added with Sample diluent. Solutions are added to the bottom of micro ELISA plate well, avoid inside wall touching and foaming as possible. Mix it gently. Cover the plate with sealer we provided. Incubate for 120 minutes at 37°C.
2. Remove the liquid from each well, don't wash. Add 100µL of Detection Reagent A working solution to each well. Cover with the Plate sealer. Gently tap the plate to ensure thorough mixing. Incubate for 1 hour at 37°C. Note: if Detection Reagent A appears cloudy warm to room temperature until solution is uniform.
3. Aspirate each well and wash, repeating the process three times. Wash by filling each well with Wash Buffer (approximately 400µL) (a squirt bottle, multi-channel pipette,manifold dispenser or automated washer are needed). Complete removal of liquid at each step is essential. After the last wash, completely remove remaining Wash Buffer by aspirating or decanting. Invert the plate and pat it against thick clean absorbent paper.
4. Add 100µL of Detection Reagent B working solution to each well. Cover with the Plate sealer. Incubate for 60 minutes at 37°C.
5. Repeat the wash process for five times as conducted in step 3.
6. Add 90µL of Substrate Solution to each well. Cover with a new Plate sealer and incubate for 10-20 minutes at 37°C. Protect the plate from light. The reaction time can be shortened or extended according to the actual color change, but this should not exceed more than 30 minutes. When apparent gradient appears in standard wells, user should terminatethe reaction.
7. Add 50µL of Stop Solution to each well. If color change does not appear uniform, gently tap the plate to ensure thorough mixing.
8. Determine the optical density (OD value) of each well at once, using a micro-plate reader set to 450 nm. User should open the micro-plate reader in advance, preheat the instrument, and set the testing parameters.
9. After experiment, store all reagents according to the specified storage temperature respectively until their expiry.

When carrying out an ELISA assay it is important to prepare your samples in order to achieve the best possible results. Below we have a list of procedures for the preparation of samples for different sample types.

Sample Type Protocol
Serum If using serum separator tubes, allow samples to clot for 30 minutes at room temperature. Centrifuge for 10 minutes at 1,000x g. Collect the serum fraction and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles. If serum separator tubes are not being used, allow samples to clot overnight at 2-8°C. Centrifuge for 10 minutes at 1,000x g. Remove serum and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles.
Plasma Collect plasma using EDTA or heparin as an anticoagulant. Centrifuge samples at 4°C for 15 mins at 1000 × g within 30 mins of collection. Collect the plasma fraction and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles. Note: Over haemolysed samples are not suitable for use with this kit.
Urine & Cerebrospinal Fluid Collect the urine (mid-stream) in a sterile container, centrifuge for 20 mins at 2000-3000 rpm. Remove supernatant and assay immediately. If any precipitation is detected, repeat the centrifugation step. A similar protocol can be used for cerebrospinal fluid.
Cell culture supernatant Collect the cell culture media by pipette, followed by centrifugation at 4°C for 20 mins at 1500 rpm. Collect the clear supernatant and assay immediately.
Cell lysates Solubilize cells in lysis buffer and allow to sit on ice for 30 minutes. Centrifuge tubes at 14,000 x g for 5 minutes to remove insoluble material. Aliquot the supernatant into a new tube and discard the remaining whole cell extract. Quantify total protein concentration using a total protein assay. Assay immediately or aliquot and store at ≤ -20 °C.
Tissue homogenates The preparation of tissue homogenates will vary depending upon tissue type. Rinse tissue with 1X PBS to remove excess blood & homogenize in 20ml of 1X PBS (including protease inhibitors) and store overnight at ≤ -20°C. Two freeze-thaw cycles are required to break the cell membranes. To further disrupt the cell membranes you can sonicate the samples. Centrifuge homogenates for 5 mins at 5000xg. Remove the supernatant and assay immediately or aliquot and store at -20°C or -80°C.
Tissue lysates Rinse tissue with PBS, cut into 1-2 mm pieces, and homogenize with a tissue homogenizer in PBS. Add an equal volume of RIPA buffer containing protease inhibitors and lyse tissues at room temperature for 30 minutes with gentle agitation. Centrifuge to remove debris. Quantify total protein concentration using a total protein assay. Assay immediately or aliquot and store at ≤ -20 °C.
Breast Milk Collect milk samples and centrifuge at 10,000 x g for 60 min at 4°C. Aliquot the supernatant and assay. For long term use, store samples at -80°C. Minimize freeze/thaw cycles.
